SPECIFICATIONS

AE***E35AX

MODEL AE093E35AX AE123E35AX AE183E35AX

Cooling (BTU's)

9500

9200

11600

11200

17800

17400

@ EER 10.0 10.0 9.7

Cooling Watts 950 - 920 1160 - 1120 1835 - 1795

Cooling Amps 4.3 - 4.5 5.2 - 5.7 8.2 - 8.8

Electric Heat 10700 - 8500 10700 - 8500 11000 - 9000

Rating Electric Heat Watts 3500 3500 3600

Actual Electric Heat Watts 3575 - 2765 3575 - 2765 3555 - 2900

Electric Heat Amps 16.0 - 14.6 16.0 - 14.6 16.0 - 15.6

Heatpump

Heatpump Watts --- --- ---

Heatpump Amps --- --- ---

Reverse Cycle Amps --- --- ---

Voltage 230 - 208 230 - 208 230 - 208

Power Cord

Rating 20 amp 20 amp 20 amp

Type LCDI LCDI LCDI

Length 6 feet 6 feet 6 feet

Dehumidification: pints / hour 2.3 2.6 4.2

Fan Speeds

CFM cooling : High-Medium-Low 280 - 230 280 - 230 450 - 390

Exhaust Air & CFM NO NO 9.5

Motor Capacitor 4uf 4uf 7uf

Controls

Thermostat temp. range 61 to 86 degrees 61 to 86 degrees 61 to 86 degrees

Energy Saver ( auto fan ) Yes Yes Yes

24 hour timer Yes Yes Yes

3 minute compressor delay Auto Auto Auto

Chassis Size

Chassis Heighth 15 3/8" 15 3/8" 16 7/8"

Chassis Width 22 5/8" 22 5/8" 26 "

Chassis Depth 24" 24" 27 3/4"
