4 Rev. 1

PRODUCT DIMENSIONS

GUIC 80% Upflow/Horizontal

FURNACE

MODEL

ABCDE

Minimum

Vent

Diameter

GUIC045

GUIC070

16-1/2 15 5-1/4 12-5/8 4 4

GUIC090

20-1/2 19 7-1/4 14-5/8 4 4

GUIC115

GUIC140

24-1/2 23 9-1/4 18-5/8 4 5

GUIC DIMENSIONS

All dimensions are in inches.

Supply

Electrical

Hole "Low

Voltage"

Gas

Supply

Hole

Electrical

Hole "High

Voltage"

Side

Cut-Out

4-5/8

28-1/4

31-5/8

23

14

37-3/8

40

28-3/4

28

20

3/4

4 5/8

Knock-Out

For

Venting

Upflow

Left Side View

1 5/8

1

Bottom Knock-Out

Upflow

Front View

Upflow

Right Side View

D

Bottom Knock-Out

3/4

3/4

C

B

A

Supply

34-5/8

31

4 11/16

Side

Cut-Out

2-1/2

23 1/2

E

1 1/2
