April 2000

Quiet Zone

Room Air Conditioner

Use And Care

Manual

RECOGNIZE THIS SYMBOL AS A SAFETY PRECAUTION

WARNING

To avoid death, personal injury or

property damage due to overheating, do

not leave this room air conditioner

unattended when used as cooling or life

support for persons or animals unable to

react to unit failure. Take precautions to

warn or guard against such an

occurrence.

Please read this Use and Care Manual thoroughly. This

manual provides proper maintenance information for maxi-

mum benefit of the features selected.

Contents

Electrical Requirements ........................................ 2

Electrical Grounding Instructions.................................. 2

Safety Features ...................................................... 2

Compressor Lockout ..................................................... 2

Low Voltage Protection .................................................. 2

Advantages of Amana’s Electronic Controls ....... 2

Operation ................................................................ 3

Vent Control ................................................................... 3

Unit Control .................................................................... 3

General Information .............................................. 6

Changing Air Flow Direction .......................................... 6

Air Flow Around Unit ...................................................... 6

Care and Maintenance .......................................... 6

Air Filter ......................................................................... 6

Before Calling For Service ................................... 7

Fan Motor ....................................................................... 7

Slide out Chassis........................................................... 7

Model Identification .............................................. 8

Any Questions? ...................................................... 8

As an ENERGY STAR

partner, AMANA

APPLIANCES has determined that models

5M11TA, 5M11TB, 7M11TA, and 18M23TB meet the

ENERGY STAR

guidelines for energy efficiency.
